Veterinary Oblique Locking L Plate 130 Degree 2.0 mm Left Right Fixation
Supports fixation across angled fracture planes with anatomical accuracy.
Maintains alignment without reliance on bone compression.
Ensures precise anatomical placement during veterinary surgery.
Allows implantation in confined anatomical regions.
Optimized for small animal orthopedic applications.
Description
The veterinary oblique locking L-plate 130° 2.0 mm with two head holes is developed for precise angular stabilization in small animal orthopedic procedures where standard straight or right-angle plates are insufficient. The 130-degree oblique configuration allows controlled fixation across angled fracture planes, making it particularly useful in anatomically complex regions.
This veterinary implant utilizes a locking screw mechanism that produces a fixed-angle construct, reducing dependence on bone compression and minimizing the risk of screw loosening. Such stability is essential in small animals where bone stock may be limited and accurate alignment is critical for healing. The oblique geometry assists surgeons in achieving correct anatomical orientation without excessive plate contouring.
Designed specifically for veterinary use, the low-profile structure helps preserve surrounding soft tissue and allows implantation in confined surgical sites. Smooth transitions between the plate arms and rounded edges reduce irritation and support postoperative comfort. The plate’s compact footprint enables precise placement while maintaining mechanical strength.
The availability of left and right orientations ensures anatomical compatibility, improving surgical efficiency and reducing intraoperative modification. Two length options—9 mm and 13 mm—provide flexibility in addressing varying fracture extents and patient sizes. This adaptability makes the implant suitable for a range of small animal cases, including cats and small-breed dogs.
The 2.0 mm locking system is compatible with standard veterinary mini locking screws, offering predictable fixation behavior and reproducible results. By combining angular control with locking stability, this oblique L-plate supports reliable fracture management in veterinary orthopedic surgery.
Manufactured for veterinary applications, the locking L-plate oblique 130° 2.0 mm delivers controlled angular fixation, anatomical adaptability, and consistent performance in advanced small animal fracture repair.
Additional information
| Implant Category | Veterinary orthopedic locking plate |
|---|---|
| Plate Geometry | Oblique L-shape (130°) |
| Variant | Oblique configuration |
| Screw Diameter | 2.0 mm locking |
| Head Holes | 3 |
| Orientation | Left / Right |
| Length Options | 9 mm, 13 mm |
| Fixation Type | Fixed-angle locking |
